Mechanical Seals
Leading Manufacturers, Exporters and Wholesaler of Closed Type Seal, Conical Spring Seal, Double Agitator Seal, Double Cartex Seal, Dry Running Seal, Grundfos Seal, Housing Type Seal, Metal Bellow Seal, Metal bellow Seal ( O-ring), Open Type Seal, RE20S Seal, Robin Type Seal, Rotary Bellow Seal, Single Agitator Seal, Single Cartex Mechanical Seal, TBG Seal and TBR Seal from Banaskantha.
| Business Type | Manufacturer, Exporter, Supplier |
| Temperature | -20 °C ... +160 °C |
| Pressure | Up To 10 Bar |
| Shaft Diameter | 10 ... 100 Mm |
| Country of Origin | India |
| Seal Ring Face | Carbon graphite antimony impregnated, Carbon graphite resin impregnated, Silicon carbide, Tungsten c |
| Mating Ring Face | Silicon carbide, Tungsten carbide, Ceramic |
| Elastomer | NBR, EPDM, FKM. |
Features :
- For plain shafts.
- Single and dual seal.
- Unbalanced
- Elastomer bellows rotating
- Independent of direction of rotation
| Business Type | Manufacturer, Exporter, Supplier |
| Usage | Gas Industry |
| Condition | New |
| Shape | Round |
| Finishing | Coated |
| Country of Origin | India |
| Shaft Diameter | 10 ... 100 m |
| Pressure | Up to 10 Bar |
| Temperature | -20 °C ... +160 °C |
| Mating Ring | Silicon carbide, Tungsten carbide |
| Secondary Seals | FKM, NBR, EPDM, Aflas, FFKM, PTFE. |
| Springs | SS 316. |
Carbon graphite resin impregnated, Carbon graphite antimony impregnated, Tungsten carbide, Silicon carbide.
Features :
- Rotating single-spring pusher seals.
- Unbalanced.
- Available as wedge variants.
- Hard/hard seal face combination available.
- Independent of direction of rotation.
- Available as single, dual and tandem arrangements.
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Ring | Carbon Graphite Resin Impregnated, Carbon Graphite |
| Mating Ring | Silicon carbide, Tungsten carbide, Ceramic. |
| Secondary Seals | PTFE, GFT, FKM, EPDM, Aflas, Kalrez, FFKM. |
| Springs | SS 316, Hastelloy C. |
| Shaft Diameter | 20 ... 80 mm. |
| Pressure | Up to 12 Bar |
| Temperature | -50 °C... +180 °C |
Features :
- Single cartridge seal.
- Balance and Unbalanced.
- Independent of direction of rotation.
- Single seals with flush and with quench combined with lip seal or throttle ring.
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Ring | Carbon graphite resin impregnated, Carbon graphite |
| Mating Ring | Silicon carbide, Tungsten carbide, Ceramic. |
| Secondary Seals | PTFE, GFT, FKM, EPDM, Aflas, Kalrez, FFKM. |
| Springs | SS 316, Hastelloy C. |
| Shaft Diameter | 20 ... 830 mm. |
| Pressure | Up to 12 Bar |
| Temperature | -50 °C ... +180 °C |
Features :
- Balance and Unbalanced.
- Available as “O” Ring & wedge variants.
- Independent of direction of rotation.
- Metric and inch sizes available.
- Variant with pumping screw available
- Single seal with quench and lip sea.
| Business Type | Manufacturer, Exporter, Supplier |
| Temperature | -40 °C ... +200 °C |
| Pressure | Up To 25 Bar |
| Shaft Diameter | 25 ... 100 Mm. |
| Country of Origin | India |
| Seal Ring | Silicon carbide, Tungsten carbide |
| Mating Ring | Silicon carbide, Tungsten carbide. |
| Secondary Seals | FKM, EPDM, Aflas, Kalrez, FFKM, TTV. |
| Springs | Hastelloy C. |
Features :
- Single cartridge seal.
- Balance and Unbalanced.
- Independent of direction of rotation.
- Single seals with flush and with quench combined with lip seal or throttle ring.
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Size | 12mm,16mm,22mm |
| Pressure | 10 Bar |
| Speed | 15 m/s |
| Temperature | 30 deg C to 200 deg C |
| Seal Characteristics | Single acting, single cartridge, unbalanced, Inside mounted |
| Operating Limits | Shaft dia: 12 mm to 50mm |
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Ring | Carbon Graphite Resin Impregnated, Carbon Graphite |
| Mating Ring | Silicon carbide, Tungsten carbide, Ceramic |
| Secondary Seals | PTFE, GFT, FKM, EPDM, Aflas, Kalrez, FFKM |
| Springs | SS 316, Hastelloy C. |
| Shaft Diameter | 20 ...80 mm. |
| Pressure | Up to 12 bar |
| Temperature | -50 °C ...+180°C |
Features :
- Balance and Unbalanced.
- Available as “O” Ring & wedge variants.
- Independent of direction of rotation.
- Metric and inch sizes available.
- Variant with pumping screw available
- Single seal with quench and lip sea.
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Ring | Carbon graphite Antimony impregnated, Silicon carbide. |
| Mating Ring | Silicon carbide. Tungsten carbide. |
| Secondary Seals | Grafoil. |
| Springs | Inconel 718 hardened, Hastelloy |
| Shaft Diameter | 20 ... 100 mm |
| Pressure | 25 Bar (max) |
| Temperature | -40 °C ... +350 °C |
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Ring | Carbon graphite Antimony impregnated, Silicon carbide. |
| Mating Ring | Silicon carbide. Tungsten carbide |
| Secondary Seals | FKM, PTFE. |
| Springs | Inconel 718 hardened, Hastelloy |
| Shaft Diameter | 20 ... 100 mm |
| Pressure | 25 Bar (max) |
| Temperature | -40 °C ... +350 °C |
Features :
- Outside Mounted Seal.
- Single Acting Seal.
- Independent of direction of rotation
- Multi Spring Design Seal.
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Ring Face | Carbon graphite antimony impregnated, Carbon graphite resin impregnated, Silicon carbide, Tungsten carbide. |
| Mating Ring Face | Silicon Carbide, Tungsten Carbide, Ceramic |
| Elastomer | NBR, EPDM, FKM. |
| Shaft Diameter | 10 ... 100 mm |
| Pressure | Up to 10 bar |
| Temperature | -20 °C ... +160 °C |
Features :
- For plain shafts.
- Single and dual seal.
- Unbalanced
- Elastomer bellows rotating
- Independent of direction of rotation
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Faces | Carbon, Ceramic (99.5%), GFT, CFT, Silicon Carbide |
| Secondary Seals | PTFE (Teflon) Bellow, Gasket |
| Springs | SS 316, SS 304, Monel, Alloy-20, @ Hastelloy-C, Spring covered by PTFE (Teflon) tube |
| Shaft Diameter | 19 ... 100 mm |
| Pressure | Up to 10 bar |
| Temperature | -30 °C ... +120 °C |
Features :
- Outside Mounted Seal.
- Single Acting Seal.
- Independent of direction of rotation
- Multi Spring Design Seal.
| Business Type | Manufacturer, Exporter, Supplier |
| Temperature | -20 °C ... +140 °C |
| Pressure | Up To 7 Bar |
| Shaft Diameter | 12 ... 100 Mm |
| Country of Origin | India |
| Seal Ring Face | Carbon graphite antimony impregnated, Carbon graphite resin impregnated, Silicon carbide, Tungsten carbide. |
| Mating Ring Face | Silicon carbide, Tungsten carbide, Ceramic |
| Elastomer | NBR, FKM, EPDM. |
| Spring | S.S 316 |
Features :
- For plain shafts.
- Single and dual seal.
- Unbalanced
- Elastomer bellows rotating
- Independent of direction of rotation
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Ring | Carbon graphite Antimony impregnated, Silicon carbide. |
| Mating Ring | Silicon carbide. Tungsten carbide |
| Secondary Seals | FKM, PTFE. |
| Springs | Inconel 718 hardened, Hastelloy |
| Shaft Diameter | 20 ... 100 mm |
| Pressure | 25 bar (Max) |
| Temperature | -40 °C ... +350 °C |
Features :
- For Unstepped shafts
- Single seal
- Balance
- Independent of direction of rotation
- Encapsulated rotating spring
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Ring | Carbon Graphite Resin Impregnated, Carbon Graphite |
| Mating Ring | Silicon carbide, Tungsten carbide, Ceramic |
| Secondary Seals | PTFE, GFT, FKM, EPDM, Aflas, Kalrez, FFKM. |
| Springs | SS 316, Hastelloy C. |
| Shaft Diameter | 20 ... 80 mm |
| Pressure | Up to 12 Bar |
| Temperature | -50 °C ... +180 °C |
Features :
- Single cartridge seal.
- Balance and Unbalanced.
- Independent of direction of rotation.
- Single seals with flush and with quench combined with lip seal or throttle ring.
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Ring | Silicon carbide, Tungsten carbide |
| Mating Ring | Silicon carbide, Tungsten carbide |
| Secondary Seals | FKM, EPDM, Aflas, Kalrez, FFKM, TTV |
| Springs | Hastelloy C. |
| Shaft Diameter | 25 ..100mm. |
| Pressure | Up to 25 Bar |
| Temperature | -40 °C ...+200°C |
Features :
- Single cartridge seal.
- Balance and Unbalanced
- Independent of direction of rotation.
- Single seals with flush and with quench combined with lip seal or throttle ring
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Seal Ring | Carbon graphite, Silicon carbide. |
| Mating Ring | Silicon carbide, Ceramic |
| Secondary Seals | PTFE. |
| Springs | Hastelloy —C. |
| Shaft Diameter | 19 ... 100 mm |
| Pressure | Up to 6 Bar |
| Temperature | -45 °C ... +120 °C |
Features :
- Outside Mounted Seal.
- Single Acting Seal.
- Independent of direction of rotation
- Multi Spring Design Seal.
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Shaft Diameter | 19 ... 100 mm |
| Pressure | Up to 6 bar |
| Temperature | -45 °C ... +120 °C |
| Seal Ring | GFT, SFT, CFT. |
| Mating Ring | Silicon carbide, Ceramic |
| Secondary Seals. | PTFE |
| Springs | Hastelloy — C. |
Features :
- Outside Mounted Seal.
- Single Acting Seal.
- Independent of direction of rotation
- Multi Spring Design Seal.
